Microsoft Azure Administrator (AZ-103) - 2
These are Microsoft Azure Administrator AZ-103 certification questions for experienced professionals. You will find these questions very helpful in your Microsoft Azure Administrator AZ-103 certification exam. Prepare well and All the very best.
All the feedbacks and suggestions are most welocome.
QUESTION 1
You have an Azure subscription that contains a virtual machine named VM1. VM1 hosts a line-of-business
application that is available 24 hours a day. VM1 has one network interface and one managed disk. VM1 uses
the D4s v3 size.
You plan to make the following changes to VM1: Change the size to D8s v3.
Add a 500-GB managed disk. Add the Puppet Agent extension.
Attach an additional network interface.
Which change will cause downtime for VM1?
A. Add the Puppet Agent extension.
B. Change the size to D8s v3.
C. Add a 500-GB managed disk.
D. Attach an additional network interface.
Correct Answer: B
Explanation:
While resizing the VM it must be in a stopped state.
References: https://azure.microsoft.com/en-us/blog/resize-virtual-machines/
QUESTION 2
You have an Azure virtual machine named VM1 that you use for testing. VM1 is protected by Azure Backup. You
delete VM1.
You need to remove the backup data stored for VM1. What should you do first?
A. Delete the Recovery Services vault.
B. Delete the storage account.
C. Stop the backup
D. Modify the backup policy.
Correct Answer: D
Explanation:
Azure Backup provides backup for virtual machines — created through both the classic deployment model
and the Azure Resource Manager deployment model — by using custom-defined backup policies in a Recovery
Services vault.
With the release of backup policy management, customers can manage backup policies and model them to meet
their changing requirements from a single window. Customers can edit a policy, associate more virtual
machines to a policy, and delete unnecessary policies to meet their compliance requirements.
Incorrect Answers:
B: You can't delete a Recovery Services vault if it is registered to a server and holds backup data. If
you try to delete a vault, but can't, the vault is still configured to receive backup data.
References: https://azure.microsoft.com/en-in/updates/azure-vm-backup-policy-management/
QUESTION 3
You have an Azure subscription named Subscription1.
You deploy a Linux virtual machine named VM1 to Subscription1. You need to monitor the metrics and the
logs of VM1.
What should you use?
A. the AzurePerformanceDiagnostics extension
B. Azure HDInsight
C. Linux Diagnostic Extension (LAD) 3.0
D. Azure Analysis Services
Correct Answer: A
Explanation:
You can use extensions to configure diagnostics on your VMs to collect additional metric data.
The basic host metrics are available, but to see more granular and VM-specific metrics, you need to install
the Azure diagnostics extension on the VM. The Azure diagnostics extension allows additional monitoring
and diagnostics data to be retrieved from the VM.
References: https://docs.microsoft.com/en-us/azure/virtual-machines/linux/tutorial-monitoring
QUESTION 4
DRAG DROP
You have an availability set named AS1 that contains three virtual machines named VM1, VM2, and VM3.
You attempt to reconfigure VM1 to use a larger size. The operation fails and you receive an allocation
failure message.
You need to ensure that the resize operation succeeds.
Which three actions should you perform in sequence? To answer, move the appropriate actions from the
list of actions to the answer area and arrange them in the correct order.
Explanation:
Step 1: Stop VM1, VM, and VM3.
If the VM you wish to resize is part of an availability set, then you must stop all VMs in the availability
set before changing the size of any VM in the availability set. The reason all VMs in the availability set
must be stopped before performing the resize operation to a size that requires different hardware is that all
running VMs in the availability set must be using the same physical hardware cluster. Therefore, if a change of
physical hardware cluster is required to change the VM size then all VMs must be first stopped and then
restarted one-by-one to a different physical hardware clusters.
Step 2: Resize VM1.
Step 3: Start VM1, VM2, and VM3. References: https://azure.microsoft.com/es-es/blog/resize-virtual-machines/
QUESTION 5
You plan to back up an Azure virtual machine named VM1.
You discover that the Backup Pre-Check status displays a status of Warning. What is a possible cause of
the Warning status?
A. VM1 is stopped.
B. VM1 does not have the latest version of WaAppAgent.exe installed.
C. VM1 has an unmanaged disk.
D. A Recovery Services vault is unavailable.
Correct Answer: B
Explanation:
The Warning state indicates one or more issues in VM’s configuration that might lead to backup failures
and provides recommended steps to ensure successful backups. Not having the latest VM Agent installed,
for example, can cause backups to fail intermittently and falls in this class of issues.
References: https://azure.microsoft.com/en-us/blog/azure-vm-backup-pre-checks/
QUESTION 6
You have an Azure subscription named Subscription1 that is used by several departments at your
company. Subscription1 contains the resources in the following table.
Another administrator deploys a virtual machine named VM1 and an Azure Storage account named Storage2 by
using a single Azure Resource Manager template.
You need to view the template used for the deployment.
From which blade can you view the template that was used for the deployment?
A. Container1
B. RG1
C. VM1
D. Storage2
Correct Answer:
Explanation:
View template from deployment history
1. Go to the resource group for your new resource group. Notice that the portal shows the result of the
last deployment. Select this link.
2. You see a history of deployments for the group. In your case, the portal probably lists only one
deployment. Select this deployment.
3. The portal displays a summary of the deployment. The summary includes the status of the deployment and
its operations and the values that you provided for parameters. To see the template that you used for the
deployment, select View template.
References: https://docs.microsoft.com/en-us/azure/azure-resource-manager/resource-manager-export-template
QUESTION 7
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You have an Azure virtual machine named VM1. VM1 was deployed by using a custom Azure Resource Manager
template named ARM1.json.
You receive a notification that VM1 will be affected by maintenance. You need to move VM1 to a different
host immediately.
Solution: From the Overview blade, you move the virtual machine to a different subscription. Does this
meet the goal?
A. Yes
B. No
Correct Answer: B
Explanation:
You would need to redeploy the VM.
References: https://docs.microsoft.com/en-us/azure/virtual-machines/windows/redeploy-to-new-node
QUESTION 8
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You have an Azure virtual machine named VM1. VM1 was deployed by using a custom Azure Resource Manager
template named ARM1.json.
You receive a notification that VM1 will be affected by maintenance. You need to move VM1 to a different
host immediately.
Solution: From the Redeploy blade, you click Redeploy. Does this meet the goal?
A. Yes
B. No
Correct Answer: A
Explanation:
When you redeploy a VM, it moves the VM to a new node within the Azure infrastructure and then powers it
back on, retaining all your configuration options and associated resources.
References: https://docs.microsoft.com/en-us/azure/virtual-machines/windows/redeploy-to-new-node
QUESTION 9
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You have an Azure virtual machine named VM1. VM1 was deployed by using a custom Azure Resource Manager
template named ARM1.json.
You receive a notification that VM1 will be affected by maintenance. You need to move VM1 to a different
host immediately.
Solution: From the Update management blade, you click Enable. Does this meet the goal?
A. Yes
B. No
Correct Answer: B
Explanation:
You would need to redeploy the VM.
References: https://docs.microsoft.com/en-us/azure/virtual-machines/windows/redeploy-to-new-node
QUESTION 10
HOTSPOT
You have an Azure subscription named Subscription1. Subscription1 contains two Azure virtual machines
named VM1 and VM2. VM1 and VM2 run Windows Server 2016.
VM1 is backed up daily by Azure Backup without using the Azure Backup agent. VM1 is affected by ransomware
that encrypts data.
You need to restore the latest backup of VM1.
To which location can you restore the backup? To answer, select the appropriate options in the answer area.
NOTE: Each correct selection is worth one point.
QUESTION 11
You download an Azure Resource Manager template based on an existing virtual machine. The template will
be used to deploy 100 virtual machines.
You need to modify the template to reference an administrative password. You must prevent the password
from being stored in plain text.
What should you create to store the password?
A. an Azure Key Vault and an access policy
B. a Recovery Services vault and a backup policy
C. Azure Active Directory (AD) Identity Protection and an Azure policy
D. an Azure Storage account and an access policy
Correct Answer: A
Explanation:
You can use a template that allows you to deploy a simple Windows VM by retrieving the password that is
stored in a Key Vault. Therefore, the password is never put in plain text in the template parameter file.
References: https://azure.microsoft.com/en-us/resources/templates/101-vm-secure-password/
QUESTION 12
HOTSPOT
You create a virtual machine scale set named Scale1. Scale1 is configured as shown in the following exhibit.
Use the drop-down menus to select the answer choice that completes each statement based on the information
presented in the graphic.
NOTE: Each correct selection is worth one point.
Explanation:
Box 1:
The Autoscale scale out rule increases the number of VMs by 2 if the CPU threshold is 80% or higher. The
initial instance count is 4 and rises to 6 when the 2 extra instances of VMs are added.
Box 2:
The Autoscale scale in rule decreases the number of VMs by 4 if the CPU threshold is 30% or lower. The
initial instance count is 4 and thus cannot be reduced to 0 as the minimum instances is set to 2. Instances
are only added when the CPU threshold reaches 80%.
References:
https://docs.microsoft.com/en-us/azure/azure-monitor/platform/autoscale-overviewi
https://docs.microsoft.com/en-us/azure/azure-monitor/platform/autoscale-best-practices
https://docs.microsoft.com/en-us/azure/azure-monitor/platform/autoscale-common-scale-patterns
QUESTION 13
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 4
You plan to back up all the Azure virtual machines in your Azure subscription at 02:00 Coordinated Universal
Time (UTC) daily.
You need to prepare the Azure environment to ensure that any new virtual machines can be configured quickly
for backup. The solution must ensure that all the daily backups performed at 02:00 UTC are stored
for only 90 days.
What should you do from your Recovery Services vault on the Azure portal?
Correct Answer: See solution below.
Explanation:
Task A: Create a Recovery Services vault (if a vault already exists skip this task, go to Task B below)
A1. From Azure Portal, On the Hub menu, click All services and in the list of resources, type Recovery
Services and click Recovery Services vaults.
If there are recovery services vaults in the subscription, the vaults are listed. A2. On the Recovery
Services vaults menu, click Add.
A3. The Recovery Services vault blade opens, prompting you to provide a Name, Subscription, Resource group,
and Location
Task B.
B1. On the Recovery Services vault blade (for the vault you just created), in the Getting Started section,
click Backup, then on the Getting Started with Backup blade, select Backup goal.
The Backup Goal blade opens. If the Recovery Services vault has been previously configured, then the Backup
Goal blades opens when you click Backup on the Recovery Services vault blade.
B2. From the Where is your workload running? drop-down menu, select Azure.
B3. From the What do you want to backup? menu, select Virtual Machine, and click OK.
B4. Finish the Wizard.
Task C. create a backup schedule
C1. Open the Microsoft Azure Backup agent. You can find it by searching your machine for Microsoft Azure
Backup.
C2. In the Backup agent's Actions pane, click Schedule Backup to launch the Schedule Backup Wizard.
C3. On the Getting started page of the Schedule Backup Wizard, click Next. C4. On the Select Items to
Backup page, click Add Items.
The Select Items dialog opens.
C5. Select Blob Storage you want to protect, and then click OK. C6. In the Select Items to Backup page,
click Next.
On the Specify Backup Schedule page, specify Schedule a backup every: day
At the following times: 2.00 AM
C7. On the Select Retention Policy page, set it to 90 days, and click Next.
C8. Finish the Wizard.
References: https://docs.microsoft.com/en-us/azure/backup/backup-configure-vault
QUESTION 14
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task5
You plan to connect several virtual machines to the VNET01-USEA2 virtual network.
In the Web-RGlod9272261 resource group, you need to create a virtual machine that uses the Standard_B2ms
size named Web01 that runs Windows Server 2016. Web01 must be added to an availability set.
What should you do from the Azure portal?
Correct Answer: See solution below.
Explanation:
Step 1: Choose Create a resource in the upper left-hand corner of the Azure portal.
Step 2: In the Basics tab, under Project details, make sure the correct subscription is selected and then
choose Web-RGlod9272261 resource group
Step 3: Under Instance details type/select: Virtual machine name: Web01
Image: Windows Server 2016 Size: Standard_B2ms size Leave the other defaults.
Step 4: Finish the Wizard
Testlet 2 Case study
This is a case study. Case studies are not timed separately. You can use as much exam time as you would
like to complete each case. However, there may be additional case studies and sections on this exam. You
must manage your time to ensure that you are able to complete all questions included on this exam in the
time provided.
To answer the questions included in a case study, you will need to reference information that is provided
in the case study. Case studies might contain exhibits and other resources that provide more information
about the scenario that is described in the case study. Each question is independent of the other questions
in this case study.
At the end of this case study, a review screen will appear. This screen allows you to review your answers
and to make changes before you move to the next section of the exam. After you begin a new section, you
cannot return to this section.
To start the case study
To display the first question in this case study, click the Next button. Use the buttons in the left pane
to explore the content of the case study before you answer the questions. Clicking these buttons displays
information such as business requirements, existing environment, and problem statements. If the case study has
an All Information tab, note that the information displayed is identical to the information displayed on the
subsequent tabs. When you are ready to answer a question, click the Question button to return to the question.
Overview
Contoso, Ltd. is a consulting company that has a main office in Montreal and two branch offices in Seattle
and New York.
The Montreal office has 2,000 employees. The Seattle office has 1,000 employees. The New York office has
200 employees.
All the resources used by Contoso are hosted on-premises.
Contoso creates a new Azure subscription. The Azure Active Directory (Azure AD) tenant uses a domain named
contoso.onmicrosoft.com. The tenant uses the P1 pricing tier.
Existing Environment
The network contains an Active Directory forest named contoso.com. All domain controllers are configured
as DNS servers and host the contoso.com DNS zone.
Contoso has finance, human resources, sales, research, and information technology departments. Each department
has an organizational unit (OU) that contains all the accounts of that respective department. All the user
accounts have the department attribute set to their respective department. New users are added frequently.
Contoso.com contains a user named User1. All the offices connect by using private links.
Contoso has data centers in the Montreal and Seattle offices. Each data center has a firewall that can be
configured as a VPN device.
All infrastructure servers are virtualized. The virtualization environment contains the servers in the
following table.
Contoso uses two web applications named App1 and App2. Each instance on each web application requires 1GB
of memory.
The Azure subscription contains the resources in the following table.
The network security team implements several network security groups (NSGs).
Planned Changes
Contoso plans to implement the following changes: Deploy Azure ExpressRoute to the Montreal office.
Migrate the virtual machines hosted on Server1 and Server2 to Azure. Synchronize on-premises Active Directory
to Azure Active Directory (Azure AD). Migrate App1 and App2 to two Azure web apps named WebApp1 and WebApp2.
Technical requirements
Contoso must meet the following technical requirements:
Ensure that WebApp1 can adjust the number of instances automatically based on the load and can scale up
to five instances.
Ensure that VM3 can establish outbound connections over TCP port 8080 to the applications servers in the
Montreal office.
Ensure that routing information is exchanged automatically between Azure and the routers in the Montreal
office.
Ensure Azure Multi-Factor Authentication (MFA) for the users in the finance department only. Ensure that
webapp2.azurewebsites.net can be accessed by using the name app2.contoso.com Connect the New York office
to VNet1 over the Internet by using an encrypted connection.
Create a workflow to send an email message when the settings of VM4 are modified. Create a custom Azure
role named Role1 that is based on the Reader role.
Minimize costs whenever possible.
QUESTION 15
You discover that VM3 does NOT meet the technical requirements. You need to verify whether the issue
relates to the NSGs.
What should you use?
A. Diagram in VNet1
B. the security recommendations in Azure Advisor
C. Diagnostic settings in Azure Monitor
D. Diagnose and solve problems in Traffic Manager profiles
E. IP flow verify in Azure Network Watcher
Correct Answer: E
Explanation:
Scenario: Contoso must meet technical requirements including:
Ensure that VM3 can establish outbound connections over TCP port 8080 to the applications servers in the
Montreal office.
IP flow verify checks if a packet is allowed or denied to or from a virtual machine. The information consists
of direction, protocol, local IP, remote IP, local port, and remote port. If the packet is denied by a
security group, the name of the rule that denied the packet is returned. While any source or destination
IP can be chosen, IP flow verify helps administrators quickly diagnose connectivity issues from or to the
internet and from or to the on-premises environment.
References: https://docs.microsoft.com/en-us/azure/network-watcher/network-watcher-ip-flow-verify-overview Question Set 1
QUESTION 1
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
Your company registers a domain name of contoso.com.
You create an Azure DNS zone named contoso.com, and then you add an A record to the zone for a host named
www that has an IP address of 131.107.1.10.
You discover that Internet hosts are unable to resolve www.contoso.com to the 131.107.1.10 IP address. You
need to resolve the name resolution issue.
Solution: You modify the name servers at the domain registrar. Does this meet the goal?
A. Yes
B. No
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
Explanation:
Modify the Name Server (NS) record.
References: https://docs.microsoft.com/en-us/azure/dns/dns-delegate-domain-azure-dns
QUESTION 2
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
Your company registers a domain name of contoso.com.
You create an Azure DNS zone named contoso.com, and then you add an A record to the zone for a host named
www that has an IP address of 131.107.1.10.
You discover that Internet hosts are unable to resolve www.contoso.com to the 131.107.1.10 IP address. You
need to resolve the name resolution issue.
Solution: You modify the SOA record in the contoso.com zone. Does this meet the goal?
A. Yes
B. No
Correct Answer: B
Section: [none]
Explanation
Explanation/Reference:
Explanation:
Modify the NS record, not the SOA record.
Note: The SOA record stores information about the name of the server that supplied the data for the zone;
the administrator of the zone; the current version of the data file; the number of seconds a secondary name
server should wait before checking for updates; the number of seconds a secondary name server should wait
before retrying a failed zone transfer; the maximum number of seconds that a secondary name server can
use data before it must either be refreshed or expire; and a default number of seconds for the time-to-
live file on resource records.
References: https://searchnetworking.techtarget.com/definition/start-of-authority-record
QUESTION 3
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
Your company registers a domain name of contoso.com.
You create an Azure DNS zone named contoso.com, and then you add an A record to the zone for a host named
www that has an IP address of 131.107.1.10.
You discover that Internet hosts are unable to resolve www.contoso.com to the 131.107.1.10 IP address. You
need to resolve the name resolution issue.
Solution: You add an NS record to the contoso.com Azure DNS zone. Does this meet the goal?
A. Yes
B. No
Correct Answer: A Section: [none] Explanation
Explanation/Reference:
Explanation:
Before you can delegate your DNS zone to Azure DNS, you need to know the name servers for your zone. The
NS record set contains the names of the Azure DNS name servers assigned to the zone.
References: https://docs.microsoft.com/en-us/azure/dns/dns-delegate-domain-azure-dns
QUESTION 4
You are troubleshooting a performance issue for an Azure Application Gateway.
You need to compare the total requests to the failed requests during the past six hours. What should you use?
A. NSG flow logs in Azure Network Watcher
B. Metrics in Application Gateway
C. Connection monitor in Azure Network Watcher
D. Diagnostics logs in Application Gateway
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/application-gateway/application-gateway-diagnostics#metrics
QUESTION 5
You have two subscriptions named Subscription1 and Subscription2. Each subscription is associated to a
different Azure AD tenant.
Subscription1 contains a virtual network named VNet1. VNet1 contains an Azure virtual machine named VM1
and has an IP address space of 10.0.0.0/16.
Subscription2 contains a virtual network named VNet2. VNet2 contains an Azure virtual machine named VM2
and has an IP address space of 10.10.0.0/24.
You need to connect VNet1 to VNet2. What should you do first?
A. Move VM1 to Subscription2.
B. Modify the IP address space of VNet2.
C. Provision virtual network gateways.
D. Move VNet1 to Subscription2.
Correct Answer: C Section: [none] Explanation
Explanation/Reference:
Explanation:
The virtual networks can be in the same or different regions, and from the same or different
subscriptions. When connecting VNets from different subscriptions, the subscriptions do not need to be
associated with the same Active Directory tenant.
Configuring a VNet-to-VNet connection is a good way to easily connect VNets. Connecting a virtual network to
another virtual network using the VNet-to-VNet connection type (VNet2VNet) is similar to creating a Site-
to-Site IPsec connection to an on-premises location. Both connectivity types use a VPN gateway to provide
a secure tunnel using IPsec/IKE, and both function the same way when communicating.
The local network gateway for each VNet treats the other VNet as a local site. This lets you specify
additional address space for the local network gateway in order to route traffic.
References: https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-howto-vnet-vnet-resource-manager-
portal
QUESTION 6
DRAG DROP
You have an Azure subscription that contains two virtual networks named VNet1 and VNet2. Virtual machines
connect to the virtual networks.
The virtual networks have the address spaces and the subnets configured as shown in the following table.
You need to add the address space of 10.33.0.0/16 to VNet1. The solution must ensure that the hosts on
VNet1 and VNet2 can communicate.
Which three actions should you perform in sequence? To answer, move the appropriate actions from the list
of actions to the answer area and arrange them in the correct order.
Select and Place:
Correct Answer:
Section: [none]
Explanation
Explanation/Reference:
Explanation:
Step 1: Remove peering between Vnet1 and VNet2.
You can't add address ranges to, or delete address ranges from a virtual network's address space once a
virtual network is peered with another virtual network. To add or remove address ranges, delete the peering,
add or remove the address ranges, then re-create the peering.
Step 2: Add the 10.44.0.0/16 address space to VNet1. Step 3: Recreate peering between VNet1 and VNet2
References: https://docs.microsoft.com/en-us/azure/virtual-network/virtual-network-manage-peering
QUESTION 7
You have an Azure subscription that contains the resources in the following table.
To which subnets can you apply NSG1?
A. the subnets on VNet2 only
B. the subnets on VNet2 and VNet3 only
C. the subnets on VNet1, VNet2, and VNet3
D. the subnets on VNet1 only
E. the subnets on VNet3 only
Correct Answer: E Section: [none] Explanation
Explanation/Reference:
Explanation:
All Azure resources are created in an Azure region and subscription. A resource can only be created in a
virtual network that exists in the same region and subscription as the resource.
References: https://docs.microsoft.com/en-us/azure/virtual-network/virtual-network-vnet-plan-design-arm
QUESTION 8
HOTSPOT
You have an Azure virtual machine named VM1 that connects to a virtual network named VNet1. VM1 has the
following configurations:
Subnet 10.0.0.0/24 Availability set: AVSet
Network security group (NSG): None Private IP address: 10.0.0.4 (dynamic) Public IP address: 40.90.219.6
(dynamic)
You deploy a standard, Internet-facing load balancer named slb1.
You need to configure slb1 to allow connectivity to VM1.
Which changes should you apply to VM1 as you configure slb1? To answer, select the appropriate options in
the answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
QUESTION 9
You have five Azure virtual machines that run Windows Server 2016. The virtual machines are configured as
web servers.
You have an Azure load balancer named LB1 that provides load balancing services for the virtual machines. You
need to ensure that visitors are serviced by the same web server for each request.
What should you configure?
A. Protocol to UDP
B. Session persistence to None
C. Session persistence to Client IP
D. Idle Time-out (minutes) to 20 Correct Answer: C
Section: [none] Explanation
Explanation/Reference:
Explanation:
You can set the sticky session in load balancer rules with setting the session persistence as the client IP.
References: https://cloudopszone.com/configure-azure-load-balancer-for-sticky-sessions/
QUESTION 10
You have the Azure virtual networks shown in the following table.
To which virtual networks can you establish a peering connection from VNet1?
A. VNet2 and VNet3 only
B. VNet2 only
C. VNet3 and VNet4 only
D. VNet2, VNet3, and VNet4
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/virtual-network/tutorial-connect-virtual-networks-portal
QUESTION 11
You have an Azure subscription that contains a policy-based virtual network gateway named GW1 and a virtual
network named VNet1.
You need to ensure that you can configure a point-to-site connection from VNet1 to an on-premises computer.
Which two actions should you perform? Each correct answer presents part of the solution.
NOTE: Each correct selection is worth one point.
A. Reset GW1.
B. Create a route-based virtual network gateway.
C. Delete GW1.
D. Add a public IP address space to VNet1.
E. Add a connection to GW1.
F. Add a service endpoint to VNet1.
Correct Answer: BC Section: [none] Explanation
Explanation/Reference:
Explanation:
B: A VPN gateway is used when creating a VPN connection to your on-premises network.
Route-based VPN devices use any-to-any (wildcard) traffic selectors, and let routing/forwarding tables
direct traffic to different IPsec tunnels. It is typically built on router platforms where each IPsec
tunnel is modeled as a network interface or VTI (virtual tunnel interface).
C: Policy-based VPN devices use the combinations of prefixes from both networks to define how traffic is
encrypted/decrypted through IPsec tunnels. It is typically built on firewall devices that perform packet
filtering. IPsec tunnel encryption and decryption are added to the packet filtering and processing engine.
Incorrect Answers:
D: Point-to-Site connections do not require a VPN device or a public-facing IP address.
References: https://docs.microsoft.com/en-us/azure/vpn-gateway/create-routebased-vpn-gateway-portal
https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-connect-multiple-policybased-rm-ps
QUESTION 12
HOTSPOT
You have an Azure subscription named Subscription1. Subscription1 contains the virtual networks in the
following table.
Subscription1 contains the virtual machines in the following table.
The firewalls on all the virtual machines are configured to allow all ICMP traffic. You add the peerings
in the following table.
For each of the following statements, select Yes if the statement is true. Otherwise, select No.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: Yes
Vnet1 and Vnet3 are peers.
Box 2: Yes
Vnet2 and Vnet3 are peers.
Box 3: No
Peering connections are non-transitive. References:
https://docs.microsoft.com/en-us/azure/architecture/reference-architectures/hybrid-networking/hub-spoke
QUESTION 13
You have an Azure subscription named Subscription1 that contains the resource groups shown in the following
table.
In RG1, you create a virtual machine named VM1 in the East Asia location. You plan to create a virtual
network named VNET1.
You need to create VNET1, and then connect VM1 to VNET1.
What are two possible ways to achieve this goal? Each correct answer presents a complete solution.
NOTE: Each correct selection is worth one point.
A. Create VNET1 in RG2, and then set East Asia as the location.
B. Create VNET1 in a new resource group in the West US location, and then set West US as the location.
C. Create VNET1 in RG1, and then set East US as the location.
D. Create VNET1 in RG2, and then set East US as the location.
E. Create VNET1 in RG1, and then set East Asia as the location.
Correct Answer: AE Section: [none] Explanation
Explanation/Reference:
QUESTION 14
You have an Azure subscription that contains a virtual network named VNet1. VNet1 contains four subnets
named Gateway, Perimeter, NVA, and Production.
The NVA subnet contains two network virtual appliances (NVAs) that will perform network traffic inspection
between the Perimeter subnet and the Production subnet.
You need to implement an Azure load balancer for the NVAs. The solution must meet the following requirements:
The NVAs must run in an active-active configuration that uses automatic failover.
The NVAs must load balance traffic to two services on the Profuction subnet. The services have different
IP addresses.
Which three actions should you perform? Each correct answer presents part of the solution.
NOTE: Each correct selection is worth one point.
A. Add two load balancing rules that have HA Ports enabled and Floating IP disabled.
B. Add a frontend IP configuration, two backend pools, and a health probe.
C. Add two load balancing rules that have HA Ports and Floating IP enabled.
D. Deploy a standard load balancer.
E. Deploy a basic load balancer.
F. Add a frontend IP configuration a backend pool, and a health probe.
Correct Answer: BCD
Section: [none]
Explanation
Explanation/Reference:
Explanation:
A standard load balancer is required for the HA ports.
Two backend pools are needed as there are two services with different IP addresses. Floating IP rule is
used where backend ports are reused.
Incorrect Answers:
F: HA Ports are not available for the basic load balancer.
References: https://docs.microsoft.com/en-us/azure/load-balancer/load-balancer-standard-overview
https://docs.microsoft.com/en-us/azure/load-balancer/load-balancer-multivip-overview
QUESTION 15
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 1
Your on-premises network uses an IP address range of 131.107.2.0 to 131.107.2.255.
You need to ensure that only device from the on-premises network can connect to the rg1lod9172796n1
storage account.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Step 1: Navigate to the rg1lod9172796n1 storage account.
Step 2: Click on the settings menu called Firewalls and virtual networks.
Step 3: Ensure that you have elected to allow access from 'Selected networks'.
Step 4: To grant access to an internet IP range, enter the address range of 131.107.2.0 to 131.107.2.255
(in CIDR format) under Firewall, Address Ranges.
References: https://docs.microsoft.com/en-us/azure/storage/common/storage-network-security
QUESTION 16
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 4
Another administrator attempts to establish connectivity between two virtual networks named VNET1 and VNET2.
The administrator reports that connections across the virtual networks fail.
You need to ensure that network connections can be established successfully between VNET1 and VNET2 as
quickly as possible.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
You can connect one VNet to another VNet using either a Virtual network peering, or an Azure VPN Gateway.
To create a virtual network gateway
Step 1: In the portal, on the left side, click +Create a resource and type 'virtual network gateway' in
search. Locate Virtual network gateway in the search return and click the entry. On the Virtual network
gateway page, click Create at the bottom of the page to open the Create virtual network gateway page.
Step 2: On the Create virtual network gateway page, fill in the values for your virtual network gateway.
Name: Name your gateway. This is not the same as naming a gateway subnet. It's the name of the gateway
object you are creating.
Gateway type: Select VPN. VPN gateways use the virtual network gateway type VPN.
Virtual network: Choose the virtual network to which you want to add this gateway. Click Virtual network
to open the 'Choose a virtual network' page. Select the VNet. If you don't see your VNet, make sure the
Location field is pointing to the region in which your virtual network is located.
Gateway subnet address range: You will only see this setting if you did not previously create a gateway subnet
for your virtual network. If you previously created a valid gateway subnet, this setting will not appear.
Step 4: Select Create New to create a Gateway subnet.
Step 5: Click Create to begin creating the VPN gateway. The settings are validated and you'll see the
"Deploying Virtual network gateway" tile on the dashboard. Creating a gateway can take up to 45 minutes. You
may need to refresh your portal page to see the completed status.
References: https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-howto-vnet-vnet-resource-manager-
portal?
QUESTION 17
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 5
You plan to configure VM1 to be accessible from the Internet.
You need to add a public IP address to the network interface used by VM1. What should you do from the
Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
You can add private and public IP addresses to an Azure network interface by completing the steps that follow.
Step 1: In Azure portal, click More services > type virtual machines in the filter box, and then click
Virtual machines.
Step 2: In the Virtual machines pane, click the VM you want to add IP addresses to. Click Network interfaces in
the virtual machine pane that appears, and then select the network interface you want to add the IP addresses
to. In the example shown in the following picture, the NIC named myNIC from the VM named myVM is selected:
Step 3: In the pane that appears for the NIC you selected, click IP configurations. Step 4: Click Create
public IP address.
Step 5: In the Create public IP address pane that appears, enter a Name, select an IP address assignment
type, a Subscription, a Resource group, and a Location, then click Create, as shown in the following picture:
References: https://docs.microsoft.com/en-us/azure/virtual-network/virtual-network-multiple-ip-addresses-portal
QUESTION 18
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 6
You need to allow RDP connections over TCP port 3389 to VM1 from the Internet. The solution must prevent
connections from the Internet over all other TCP ports.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Step 1: Create a new network security group Step 2: Select your new network security group.
Step 3: Select Inbound security rules. Under Add inbound security rule, enter the following Destination:
Select Network security group, and then select the security group you created previously. Destination port
ranges: 3389
Protocol: Select TCP
References: https://docs.microsoft.com/en-us/azure/virtual-network/tutorial-filter-network-traffic
QUESTION 19
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab.
Task 5
You plan to create 100 Azure virtual machines on each of the following three virtual networks:
VNET1005a VNET1005b VNET1005c
All the network traffic between the three virtual networks will be routed through VNET1005a.
You need to create the virtual networks, and then to ensure that all the Azure virtual machines can connect
to other virtual machines by using their private IP address. The solution must NOT require any virtual
network gateways and must minimize the number of peerings.
What should you do from the Azure portal before you configure IP routing?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Step 1: Click Create a resource in the portal.
Step 2: Enter Virtual network in the Search the Marketplace box at the top of the New pane that appears. Click
Virtual network when it appears in the search results.
Step 3: Select Classic in the Select a deployment model box in the Virtual Network pane that appears,
then click Create.
Step 4: Enter the following values on the Create virtual network (classic) pane and then click Create:
Name: VNET1005a
Address space: 10.0.0.0/16 Subnet name: subnet0 Resource group: Create new
Subnet address range: 10.0.0.0/24
Subscription and location: Select your subscription and location.
Step 5: Repeat steps 3-5 for VNET1005b (10.1.0.0/16, 10.1.0.0/24), and for VNET1005c 10.2.0.0/16, 10.2.0.0/24).
References: https://docs.microsoft.com/en-us/azure/virtual-network/create-virtual-network-classic
QUESTION 20
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able to
return to the lab.
You may now click next to proceed to the lab.
Task 6
You plan to create several virtual machines in different availability zones, and then to configure the
virtual machines for load balanced connections from the Internet.
You need to create an IP address resource named ip1006 to support the planned load balancing solution. The
solution must minimize costs.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
We should create a public IP address.
Step 1: At the top, left corner of the portal, select + Create a resource.
Step 2: Enter public ip address in the Search the Marketplace box. When Public IP address appears in the
search results, select it.
Step 3: Under Public IP address, select Create.
Step 4: Enter, or select values for the following settings, under Create public IP address, then select Create:
Name: ip1006 SKU: Basic SKU IP Version: IPv6
IP address assignment: Dynamic Subscription: Select appropriate Resource group: Select appropriate
References: https://docs.microsoft.com/en-us/azure/virtual-network/virtual-network-public-ip-address
QUESTION 21
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab.
Task 8
You need to create a virtual network named VNET1008 that contains three subnets named subnet0, subnet1,
and subnet2. The solution must meet the following requirements:
Connections from any of the subnets to the Internet must be blocked. Connections from the Internet to any
of the subnets must be blocked.
The number of network security groups (NSGs) and NSG rules must be minimized.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Step 1: Click Create a resource in the portal.
Step 2: Enter Virtual network in the Search the Marketplace box at the top of the New pane that appears. Click
Virtual network when it appears in the search results.
Step 3: Select Classic in the Select a deployment model box in the Virtual Network pane that appears, then
click Create.
Step 4: Enter the following values on the Create virtual network (classic) pane and then click Create:
Name: VNET1008
Address space: 10.0.0.0/16 Subnet name: subnet0 Resource group: Create new
Subnet address range: 10.0.0.0/24
Subscription and location: Select your subscription and location.
Step 5: In the portal, you can create only one subnet when you create a virtual network. Click Subnets
(in the SETTINGS section) on the Create virtual network (classic) pane that appears.
Click +Add on the VNET1008 - Subnets pane that appears.
Step 6: Enter subnet1 for Name on the Add subnet pane. Enter 10.0.1.0/24 for Address range. Click OK.
Step 7: Create the third subnet: Click +Add on the VNET1008 - Subnets pane that appears. Enter subnet2
for Name on the Add subnet pane. Enter 10.0.2.0/24 for Address range. Click OK.
References: https://docs.microsoft.com/en-us/azure/virtual-network/create-virtual-network-classic
QUESTION 22
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You manage a virtual network named VNet1 that is hosted in the West US Azure region. VNet1 hosts two
virtual machines named VM1 and VM2 that run Windows Server.
You need to inspect all the network traffic from VM1 to VM2 for a period of three hours. Solution: From
Azure Network Watcher, you create a connection monitor.
Does this meet the goal?
A. Yes
B. No
Correct Answer: A Section: [none] Explanation
Explanation/Reference:
References:
https://azure.microsoft.com/en-us/updates/general-availability-azure-network-watcher-connection-monitor-
in-all-public-regions/
QUESTION 23
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You manage a virtual network named VNet1 that is hosted in the West US Azure region. VNet1 hosts two
virtual machines named VM1 and VM2 that run Windows Server.
You need to inspect all the network traffic from VM1 to VM2 for a period of three hours. Solution: From
Azure Network Watcher, you create a packet capture.
Does this meet the goal?
A. Yes
B. No
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
Explanation:
Use the Connection Monitor feature of Azure Network Watcher.
References:
https://azure.microsoft.com/en-us/updates/general-availability-azure-network-watcher-connection-monitor-
in-all-public-regions/
QUESTION 24
HOTSPOT
Subscription1 contains the virtual machines in the following table.
In Subscription1, you create a load balancer that has the following configurations: Name: LB1
SKU: Basic Type: Internal
Subnet: Subnet12 Virtual network: VNET1
For each of the following statements, select Yes if the statement is true. Otherwise, select No.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/load-balancer/load-balancer-standard-overview
QUESTION 25
You have an Azure subscription named Subscription1 that contains two Azure virtual networks named VNet1
and VNet2. VNet1 contains a VPN gateway named VPNGW1 that uses static routing. There is a site- to-site
VPN connection between your on-premises network and VNet1.
On a computer named Client1 that runs Windows 10, you configure a point-to-site VPN connection to VNet1.
You configure virtual network peering between VNet1 and VNet2. You verify that you can connect to VNet2
from the on-premises network. Client1 is unable to connect to VNet2.
You need to ensure that you can connect Client1 to VNet2. What should you do?
A. Select Allow gateway transit on VNet2.
B. Enable BGP on VPNGW1.
C. Select Allow gateway transit on VNet1.
D. Download and re-install the VPN client configuration package on Client1.
Correct Answer: D
Section: [none]
Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/vpn-gateway/vpn-gateway-about-point-to-site-routing
QUESTION 26
Note: This question is part of a series of questions that present the same scenario. Each question in the
series contains a unique solution that might meet the stated goals. Some question sets might have more
than one correct solution, while others might not have a correct solution.
After you answer a question in this section, you will NOT be able to return to it. As a result, these
questions will not appear in the review screen.
You manage a virtual network named VNet1 that is hosted in the West US Azure region. VNet1 hosts two
virtual machines named VM1 and VM2 that run Windows Server.
You need to inspect all the network traffic from VM1 to VM2 for a period of three hours. Solution: From
Performance Monitor, you create a Data Collector Set (DCS).
Does this meet the goal?
A. Yes
B. No
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
Explanation:
Use the Connection Monitor feature of Azure Network Watcher.
References: https://docs.microsoft.com/en-us/azure/network-watcher/network-watcher-monitoring-overview
QUESTION 27
HOTSPOT
You have a virtual network named VNet1 that has the configuration shown in the following exhibit.
Use the drop-down menus to select the answer choice that completes each statement based on the information
presented in the graphic.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: add an address space
Your IaaS virtual machines (VMs) and PaaS role instances in a virtual network automatically receive
a private IP address from a range that you specify, based on the address space of the subnet they are
connected to. We need to add the 192.168.1.0/24 address space.
Box 2: add a network interface
The 10.2.1.0/24 network exists. We need to add a network interface.
References: https://docs.microsoft.com/en-us/office365/enterprise/designing-networking-for-microsoft-azure-iaas
https://docs.microsoft.com/en-us/azure/virtual-network/virtual-networks-static-private-ip-arm-pportal
QUESTION 28
HOTSPOT
You have an Azure subscription named Subscription1. Subscription1 contains the virtual machines in the
following table.
Subscription1 contains a virtual network named VNet1 that has the subnets in the following table.
VM3 has multiple network adapters, including a network adapter named NIC3. IP forwarding is enabled on
NIC3. Routing is enabled on VM3.
You create a route table named RT1 that contains the routes in the following table.
You apply RT1 to Subnet1 and Subnet2.
For each of the following statements, select Yes if the statement is true. Otherwise, select No.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
IP forwarding enables the virtual machine a network interface is attached to:
Receive network traffic not destined for one of the IP addresses assigned to any of the IP configurations
assigned to the network interface.
Send network traffic with a different source IP address than the one assigned to one of a network interface's
IP configurations.
The setting must be enabled for every network interface that is attached to the virtual machine that
receives traffic that the virtual machine needs to forward. A virtual machine can forward traffic whether
it has multiple network interfaces or a single network interface attached to it.
Box 1: Yes
The routing table allows connections from VM3 to VM1 and VM2. And as IP forwarding is enabled on VM3,
VM3 can connect to VM1.
Box 2: No
VM3, which has IP forwarding, must be turned on, in order for VM2 to connect to VM1.
Box 3: Yes
The routing table allows connections from VM1 and VM2 to VM3. IP forwarding on VM3 allows VM1 to connect
to VM2 via VM3.
References: https://docs.microsoft.com/en-us/azure/virtual-network/virtual-networks-udr-overview
https://www.quora.com/What-is-IP-forwarding
QUESTION 29
You have an Azure subscription that contains the resources in the following table.
VM1 and VM2 are deployed from the same template and host line-of-business applications accessed by using
Remote Desktop.
You configure the network security group (NSG) shown in the exhibit. (Click the Exhibit tab.)
You need to prevent users of VM2 and VM2 from accessing websites on the Internet over TCP port 80. What
should you do?
A. Change the DenyWebSites outbound security rule.
B. Change the Port_80 inbound security rule.
C. Disassociate the NSG from a network interface.
D. Associate the NSG to Subnet1.
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
Explanation:
You can associate or dissociate a network security group from a network interface or subnet.
The NSG has the appropriate rule to block users from accessing the Internet. We just need to associate it
with Subnet1.
References: https://docs.microsoft.com/en-us/azure/virtual-network/manage-network-security-group
QUESTION 30
HOTSPOT
You are creating an Azure load balancer.
You need to add an IPv6 load balancing rule to the load balancer.
How should you complete the Azure PowerShell script? To answer, select the appropriate options in the
answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/load-balancer/load-balancer-ipv6-internet-ps
QUESTION 31
HOTSPOT
You have an Azure subscription named Subscription1 that contains a resource group named RG1. In RG1,
you create an internal load balancer named LB1 and a public load balancer named LB2.
You need to ensure that an administrator named Admin1 can manage LB1 and LB2. The solution must follow
the principle of least privilege.
Which role should you assign to Admin1 for each task? To answer, select the appropriate options in the
answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
QUESTION 32
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 7
You plan to allow connections between the VNET01-USEA2 and VNET01-USWE2 virtual networks.
You need to ensure that virtual machines can communicate across both virtual networks by using their
private IP address. The solution must NOT require any virtual network gateways.
What should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Virtual network peering enables you to seamlessly connect two Azure virtual networks. Once peered, the
virtual networks appear as one, for connectivity purposes.
Peer virtual networks
Step 1. In the Search box at the top of the Azure portal, begin typing VNET01-USEA2. When VNET01- USEA2
appears in the search results, select it.
Step 2. Select Peerings, under SETTINGS, and then select + Add, as shown in the following picture:
Step 3. Enter, or select, the following information, accept the defaults for the remaining settings,
and then select OK.
Name: myVirtualNetwork1-myVirtualNetwork2 (for example) Subscription: elect your subscription.
Virtual network: VNET01-USWE2 - To select the VNET01-USWE2 virtual network, select Virtual network, then
select VNET01-USWE2. You can select a virtual network in the same region or in a different region.
Now we need to repeat steps 1-3 for the other network VNET01-USWE2:
Step 4. In the Search box at the top of the Azure portal, begin typing VNET01- USEA2. When VNET01-
USEA2 appears in the search results, select it.
Step 5. Select Peerings, under SETTINGS, and then select + Add. References:
https://docs.microsoft.com/en-us/azure/virtual-network/tutorial-connect-virtual-networks-portal
QUESTION 33
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab. Use the following login credentials as needed:
Azure Username: XXXXXXX
Azure Password: XXXXXXX
The following information is for technical support purposes only:
Lab Instance: 9172796
Task 8
You plan to host several secured websites on Web01.
You need to allow HTTPS over TCP port 443 to Web01 and to prevent HTTP over TCP port 80 to Web01. What
should you do from the Azure portal?
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
You can filter network traffic to and from Azure resources in an Azure virtual network with a network
security group. A network security group contains security rules that allow or deny inbound network traffic
to, or outbound network traffic from, several types of Azure resources.
A network security group contains security rules that allow or deny inbound network traffic to, or outbound
network traffic from, several types of Azure resources.
Step A: Create a network security group
A1. Search for and select the resource group for the VM, choose Add, then search for and select Network
security group.
A2. Select Create.
The Create network security group window opens. A3. Create a network security group
Enter a name for your network security group.
Select or create a resource group, then select a location. A4. Select Create to create the network
security group.
Step B: Create an inbound security rule to allows HTTPS over TCP port 443 B1. Select your new network
security group.
B2. Select Inbound security rules, then select Add. B3. Add inbound rule
B4. Select Advanced.
From the drop-down menu, select HTTPS.
You can also verify by clicking Custom and selecting TCP port, and 443. B5. Select Add to create the rule.
Repeat step B2-B5 to deny TCP port 80
B6. Select Inbound security rules, then select Add. B7. Add inbound rule
B8. Select Advanced.
Clicking Custom and selecting TCP port, and 80. B9. Select Deny.
Step C: Associate your network security group with a subnet
Your final step is to associate your network security group with a subnet or a specific network interface.
C1. In the Search resources, services, and docs box at the top of the portal, begin typing Web01. When
the Web01 VM appears in the search results, select it.
C2. Under SETTINGS, select Networking. Select Configure the application security groups, select the Security
Group you created in Step A, and then select Save, as shown in the following picture:
References: https://docs.microsoft.com/en-us/azure/virtual-network/tutorial-filter-network-traffic
Testlet 2
Case study
This is a case study. Case studies are not timed separately. You can use as much exam time as you would
like to complete each case. However, there may be additional case studies and sections on this exam. You
must manage your time to ensure that you are able to complete all questions included on this exam in the
time provided.
To answer the questions included in a case study, you will need to reference information that is provided
in the case study. Case studies might contain exhibits and other resources that provide more information
about the scenario that is described in the case study. Each question is independent of the other questions
in this case study.
At the end of this case study, a review screen will appear. This screen allows you to review your answers
and to make changes before you move to the next section of the exam. After you begin a new section, you
cannot return to this section.
To start the case study
To display the first question in this case study, click the Next button. Use the buttons in the left pane
to explore the content of the case study before you answer the questions. Clicking these buttons displays
information such as business requirements, existing environment, and problem statements. If the case study has
an All Information tab, note that the information displayed is identical to the information displayed on the
subsequent tabs. When you are ready to answer a question, click the Question button to return to the question.
Overview
Humongous Insurance is an insurance company that has three offices in Miami, Tokyo and Bangkok. Each office
has 5.000 users.
Existing Environment
Active Directory Environment
Humongous Insurance has a single-domain Active Directory forest named humongousinsurance.com. The functional
level of the forest is Windows Server 2012.
You recently provisioned an Azure Active Directory (Azure AD) tenant.
Network Infrastructure
Each office has a local data center that contains all the servers for that office. Each office has a
dedicated connection to the Internet.
Each office has several link load balancers that provide access to the servers.
Active Directory Issue
Several users in humongousinsurance.com have UPNs that contain special characters. You suspect that some
of the characters are unsupported in Azure AD.
Licensing Issue
You attempt to assign a license in Azure to several users and receive the following error message:
"Licenses not assigned. License assignment failed for one user."
You verify that the Azure subscription has the available licenses.
Requirements Planned Changes
Humongous Insurance plans to open a new office in Paris. The Paris office will contain 1,000 users who will
be hired during the next 12 months. All the resources used by the Paris office users will be hosted in Azure.
Planned Azure AD Infrastructure
The on-premises Active Directory domain will be synchronized to Azure AD.
All client computers in the Paris office will be joined to an Azure AD domain.
Planned Azure Networking Infrastructure
You plan to create the following networking resources in a resource group named All_Resources:
Default Azure system routes that will be the only routes used to route traffic
A virtual network named Paris-VNet that will contain two subnets named Subnet1 and Subnet2 A virtual
network named ClientResources-VNet that will contain one subnet named ClientSubnet
A virtual network named AllOffices-VNet that will contain two subnets named Subnet3 and Subnet4
You plan to enable peering between Paris-VNet and AllOffices-VNet. You will enable the Use remote gateways
setting for the Paris-VNet peerings.
You plan to create a private DNS zone named humongousinsurance.local and set the registration network to
the ClientResources-VNet virtual network.
Planned Azure Computer Infrastructure
Each subnet will contain several virtual machines that will run either Windows Server 2012 R2, Windows
Server 2016, or Red Hat Linux.
Department Requirements
Humongous Insurance identifies the following requirements for the company's departments:
Web administrators will deploy Azure web apps for the marketing department. Each web app will be added to a
separate resource group. The initial configuration of the web apps will be identical. The web administrators
have permission to deploy web apps to resource groups.
During the testing phase, auditors in the finance department must be able to review all Azure costs from
the past week.
Authentication Requirements
Users in the Miami office must use Azure Active Directory Seamless Single Sign-on (Azure AD Seamless SSO)
when accessing resources in Azure.
QUESTION 1
HOTSPOT
You are evaluating the name resolution for the virtual machines after the planned implementation of the
Azure networking infrastructure.
For each of the following statements, select Yes if the statement is true. Otherwise, select No.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: Yes
All client computers in the Paris office will be joined to an Azure AD domain.
A virtual network named Paris-VNet that will contain two subnets named Subnet1 and Subnet2
Box 2: Yes
A virtual network named ClientResources-VNet that will contain one subnet named ClientSubnet
You plan to create a private DNS zone named humongousinsurance.local and set the registration network to
the ClientResources-VNet virtual network.
Box 3: No
Only VMs in the registration network, here the ClientResources-VNet, will be able to register hostname records.
References: https://docs.microsoft.com/en-us/azure/dns/private-dns-overview
Testlet 3 Case study
This is a case study. Case studies are not timed separately. You can use as much exam time as you would
like to complete each case. However, there may be additional case studies and sections on this exam. You
must manage your time to ensure that you are able to complete all questions included on this exam in the
time provided.
To answer the questions included in a case study, you will need to reference information that is provided
in the case study. Case studies might contain exhibits and other resources that provide more information
about the scenario that is described in the case study. Each question is independent of the other questions
in this case study.
At the end of this case study, a review screen will appear. This screen allows you to review your answers
and to make changes before you move to the next section of the exam. After you begin a new section, you
cannot return to this section.
To start the case study
To display the first question in this case study, click the Next button. Use the buttons in the left pane
to explore the content of the case study before you answer the questions. Clicking these buttons displays
information such as business requirements, existing environment, and problem statements. If the case study has
an All Information tab, note that the information displayed is identical to the information displayed on the
subsequent tabs. When you are ready to answer a question, click the Question button to return to the question.
Overview
Contoso, Ltd. is a consulting company that has a main office in Montreal and two branch offices in Seattle
and New York.
The Montreal office has 2,000 employees. The Seattle office has 1,000 employees. The New York office has
200 employees.
All the resources used by Contoso are hosted on-premises.
Contoso creates a new Azure subscription. The Azure Active Directory (Azure AD) tenant uses a domain named
contoso.onmicrosoft.com. The tenant uses the P1 pricing tier.
Existing Environment
The network contains an Active Directory forest named contoso.com. All domain controllers are configured
as DNS servers and host the contoso.com DNS zone.
Contoso has finance, human resources, sales, research, and information technology departments. Each department
has an organizational unit (OU) that contains all the accounts of that respective department. All the user
accounts have the department attribute set to their respective department. New users are added frequently.
Contoso.com contains a user named User1. All the offices connect by using private links.
Contoso has data centers in the Montreal and Seattle offices. Each data center has a firewall that can be
configured as a VPN device.
All infrastructure servers are virtualized. The virtualization environment contains the servers in the
following table.
Contoso uses two web applications named App1 and App2. Each instance on each web application requires 1GB
of memory.
The Azure subscription contains the resources in the following table.
The network security team implements several network security groups (NSGs).
Planned Changes
Contoso plans to implement the following changes: Deploy Azure ExpressRoute to the Montreal office.
Migrate the virtual machines hosted on Server1 and Server2 to Azure. Synchronize on-premises Active Directory
to Azure Active Directory (Azure AD). Migrate App1 and App2 to two Azure web apps named WebApp1 and WebApp2.
Technical requirements
Contoso must meet the following technical requirements:
Ensure that WebApp1 can adjust the number of instances automatically based on the load and can scale up
to five instances.
Ensure that VM3 can establish outbound connections over TCP port 8080 to the applications servers in the
Montreal office.
Ensure that routing information is exchanged automatically between Azure and the routers in the Montreal
office.
Ensure Azure Multi-Factor Authentication (MFA) for the users in the finance department only. Ensure that
webapp2.azurewebsites.net can be accessed by using the name app2.contoso.com Connect the New York office
to VNet1 over the Internet by using an encrypted connection.
Create a workflow to send an email message when the settings of VM4 are modified. Create a custom Azure
role named Role1 that is based on the Reader role.
Minimize costs whenever possible.
QUESTION 1
HOTSPOT
You need to meet the connection requirements for the New York office.
What should you do? To answer, select the appropriate options in the answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: Create a virtual network gateway and a local network gateway.
Azure VPN gateway. The VPN gateway service enables you to connect the VNet to the on-premises network
through a VPN appliance. For more information, see Connect an on-premises network to a Microsoft Azure
virtual network. The VPN gateway includes the following elements:
Virtual network gateway. A resource that provides a virtual VPN appliance for the VNet. It is responsible
for routing traffic from the on-premises network to the VNet.
Local network gateway. An abstraction of the on-premises VPN appliance. Network traffic from the cloud
application to the on-premises network is routed through this gateway.
Connection. The connection has properties that specify the connection type (IPSec) and the key shared with
the on-premises VPN appliance to encrypt traffic.
Gateway subnet. The virtual network gateway is held in its own subnet, which is subject to various
requirements, described in the Recommendations section below.
Box 2: Configure a site-to-site VPN connection
On premises create a site-to-site connection for the virtual network gateway and the local network gateway.
Scenario: Connect the New York office to VNet1 over the Internet by using an encrypted connection. Incorrect
Answers:
Azure ExpressRoute: Established between your network and Azure, through an ExpressRoute partner. This
connection is private. Traffic does not go over the internet.
References: https://docs.microsoft.com/en-us/azure/architecture/reference-architectures/hybrid-networking/vpn
Question Set 1
QUESTION 1
You have an Azure Active Directory (Azure AD) tenant named contoso.onmicrosoft.com. The User administrator
role is assigned to a user named Admin1.
An external partner has a Microsoft account that uses the user1@outlook.com sign in.
Admin1 attempts to invite the external partner to sign in to the Azure AD tenant and receives the following
error message: “Unable to invite user user1@outlook.com – Generic authorization exception.”
You need to ensure that Admin1 can invite the external partner to sign in to the Azure AD tenant. What
should you do?
A. From the Roles and administrators blade, assign the Security administrator role to Admin1.
B. From the Organizational relationships blade, add an identity provider.
C. From the Custom domain names blade, add a custom domain.
D. From the Users blade, modify the External collaboration settings.
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
References:
https://techcommunity.microsoft.com/t5/Azure-Active-Directory/Generic-authorization-exception-inviting-
Azure-AD-gests/td-p/274742
QUESTION 2
Your company has an Azure Active Directory (Azure AD) tenant named contoso.com that is configured for
hybrid coexistence with the on-premises Active Directory domain. The tenant contains the users shown in
the following table.
Whenever possible, you need to enable Azure Multi-Factor Authentication (MFA) for the users in contoso.com.
Which users should you enable for Azure MFA?
A. User1 only
B. User1, User2, and User3 only
C. User1 and User2 only
D. User1, User2, User3, and User4
E. User2 only
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
QUESTION 3
You have two Azure Active Directory (Azure AD) tenants named contoso.com and fabrikam.com. You have a
Microsoft account that you use to sign in to both tenants.
You need to configure the default sign-in tenant for the Azure portal. What should you do?
A. From Azure Cloud Shell, run Set-AzureRmSubscription.
B. From Azure Cloud Shell, run Set-AzureRmContext.
C. From the Azure portal, configure the portal settings.
D. From the Azure portal, change the directory.
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
Explanation:
The Set-AzureRmContext cmdlet sets authentication information for cmdlets that you run in the current
session. The context includes tenant, subscription, and environment information.
References: https://docs.microsoft.com/en-us/powershell/module/azurerm.profile/set-azurermcontext
QUESTION 4
You have an Azure Active Directory (Azure AD) tenant.
All administrators must enter a verification code to access the Azure portal.
You need to ensure that the administrators can access the Azure portal only from your on-premises network.
What should you configure?
A. an Azure AD Identity Protection user risk policy.
B. the multi-factor authentication service settings.
C. the default for all the roles in Azure AD Privileged Identity Management
D. an Azure AD Identity Protection sign-in risk policy
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
QUESTION 5
You have an Active Directory forest named contoso.com.
You install and configure Azure AD Connect to use password hash synchronization as the single sign-on
(SSO) method. Staging mode is enabled.
You review the synchronization results and discover that the Synchronization Service Manager does not
display any sync jobs.
You need to ensure that the synchronization completes successfully. What should you do?
A. Run Azure AD Connect and set the SSO method to Pass-through Authentication.
B. From Synchronization Service Manager, run a full import.
C. From Azure PowerShell, run Start-AdSyncSyncCycle –PolicyType Initial.
D. Run Azure AD Connect and disable staging mode.
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
Explanation:
Staging mode must be disabled. If the Azure AD Connect server is in staging mode, password hash synchronization
is temporarily disabled.
References: https://docs.microsoft.com/en-us/azure/active-directory/connect/active-directory-aadconnectsync-
troubleshoot-password-hash-synchronization#no-passwords-are-synchronized-troubleshoot-by-using-the-
troubleshooting-task
QUESTION 6
You have an Azure Active Directory (Azure AD) tenant named contoso.onmicrosoft.com.
You hire a temporary vendor. The vendor uses a Microsoft account that has a sign-in of user1@outlook.com.
You need to ensure that the vendor can authenticate to the tenant by using user1@outlook.com. What should
you do?
A. From the Azure portal, add a custom domain name, create a new Azure AD user, and then specify
user1@outlook.com as the username.
B. From Azure Cloud Shell, run the New-AzureADUser cmdlet and specify the
–UserPrincipalName user1@outlook.com parameter.
C. From the Azure portal, add a new guest user, and then specify user1@outlook.com as the email address.
D. From Windows PowerShell, run the New-AzureADUser cmdlet and specify the
–UserPrincipalName user1@outlook.com parameter.
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
Explanation:
UserPrincipalName - contains the UserPrincipalName (UPN) of this user. The UPN is what the user will use
when they sign in into Azure AD. The common structure is @, so for Abby Brown in Contoso.com, the UPN
would be AbbyB@contoso.com
Example:
To create the user, call the New-AzureADUser cmdlet with the parameter values:
powershell New-AzureADUser -AccountEnabled $True -DisplayName "Abby Brown" -PasswordProfile
$PasswordProfile -MailNickName "AbbyB" -UserPrincipalName "AbbyB@contoso.com"
References:
https://docs.microsoft.com/bs-cyrl-ba/powershell/azure/active-directory/new-user-sample?view=azureadps- 2.0
QUESTION 7
You have an Azure Active Directory (Azure AD) tenant named contosocloud.onmicrosoft.com. Your company has
a public DNS zone for contoso.com.
You add contoso.com as a custom domain name to Azure AD. You need to ensure that Azure can verify the
domain name.
Which type of DNS record should you create?
A. MX
B. SRV
C. DNSKEY
D. NSEC
Correct Answer: A Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/dns/dns-web-sites-custom-domain
QUESTION 8
You set the multi-factor authentication status for a user named admin1@contoso.com to Enabled. Admin1
accesses the Azure portal by using a web browser.
Which additional security verifications can Admin1 use when accessing the Azure portal?
A. a phone call, a text message that contains a verification code, and a notification or a verification
code sent from the Microsoft Authenticator app
B. an app password, a text message that contains a verification code, and a notification sent from the
Microsoft Authenticator app
C. an app password, a text message that contains a verification code, and a verification code sent from
the Microsoft Authenticator app
D. a phone call, an email message that contains a verification code, and a text message that contains an
app password
Correct Answer: A Section: [none] Explanation
Explanation/Reference:
QUESTION 9
DRAG DROP
You have an Azure Active Directory (Azure AD) tenant that has the initial domain name. You have a domain
name of contoso.com registered at a third-party registrar.
You need to ensure that you can create Azure AD users that have names containing a suffix of @contoso.com.
Which three actions should you perform in sequence? To answer, move the appropriate cmdlets from the list
of cmdlets to the answer area and arrange them in the correct order.
Select and Place:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
References: https://docs.microsoft.com/en-us/azure/dns/dns-web-sites-custom-domain
QUESTION 10
Your company has a main office in London that contains 100 client computers. Three years ago, you migrated
to Azure Active Directory (Azure AD).
The company’s security policy states that all personal devices and corporate-owned devices must be
registered or joined to Azure AD.
A remote user named User1 is unable to join a personal device to Azure AD from a home network. You verify
that other users can join their devices to Azure AD.
You need to ensure that User1 can join the device to Azure AD. What should you do?
A. From the Device settings blade, modify the Users may join devices to Azure AD setting.
B. From the Device settings blade, modify the Maximum number of devices per user setting.
C. Create a point-to-site VPN from the home network of User1 to Azure.
D. Assign the User administrator role to User1.
Correct Answer: B Section: [none] Explanation
Explanation/Reference:
Explanation:
The Maximum number of devices setting enables you to select the maximum number of devices that a user can
have in Azure AD. If a user reaches this quota, they will not be able to add additional devices until one
or more of the existing devices are removed.
Incorrect Answers:
A: The Users may join devices to Azure AD setting enables you to select the users who can join devices to
Azure AD. Options are All, Selected and None. The default is All.
C: Azure AD Join enables users to join their devices to Active Directory from anywhere as long as they
have connectivity with the Internet.
References: https://docs.microsoft.com/en-us/azure/active-directory/devices/device-management-azure-portal
http://techgenix.com/pros-and-cons-azure-ad-join/
QUESTION 11
You have an Azure DNS zone named adatum.com.
You need to delegate a subdomain named research.adatum.com to a different DNS server in Azure. What should
you do?
A. Create an A record named *.research in the adatum.com zone.
B. Create a PTR record named research in the adatum.com zone.
C. Modify the SOA record of adatum.com.
D. Create an NS record named research in the adatum.com zone.
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
Explanation:
You need to create a name server (NS) record for the zone.
References: https://docs.microsoft.com/en-us/azure/dns/delegate-subdomain
QUESTION 12
SIMULATION
Please wait while the virtual machine loads. Once loaded, you may proceed to the lab section. This may
take a few minutes, and the wait time will not be deducted from your overall test time.
When the Next button is available, click it to access the lab section. In this section, you will perform
a set of tasks in a live environment. While most functionality will be available to you as it would be
in a live environment, some functionality (e.g, copy and paste, ability to navigate to external websites)
will not be possible by design.
Scoring is based on the outcome of performing the tasks stated in the lab. In other words, it doesn’t
matter how you accomplish the task, if you successfully perform it, you will earn credit for that task.
Labs are not timed separately, and this exam may have more than one lab that you must complete. You can
use as much time as you would like to complete each lab. But, you should manage your time appropriately
to ensure that you are able to complete the lab(s) and all other sections of the exam in the time provided.
Please note that once you submit your work by clicking the Next button within a lab, you will NOT be able
to return to the lab.
You may now click next to proceed to the lab.
Task 7
You plan to deploy several Azure virtual machines and to connect them to a virtual network named VNET1007.
You need to ensure that future virtual machines on VNET1007 can register their name in an internal DNS
zone named corp9172795.com. The zone must NOT be hosted on a virtual machine.
What should you do from Azure Cloud Shell?
To complete this task, start Azure Cloud Shell and select PowerShell (Linux). Click Show Advanced Settings,
and then enter corp9172795n1 in the Storage account text box and File1 in the File share text box. Click
Create storage, and then complete the task.
Correct Answer: See solution below.
Section: [none] Explanation
Explanation/Reference:
Explanation:
Step 1: New-AzureRMResourceGroup -name MyResourceGroup
Before you create the DNS zone, create a resource group to contain the DNS zone.
Step 2: New-AzureRmDnsZone -Name corp9172795.com -ResourceGroupName MyResourceGroup
A DNS zone is created by using the New-AzureRmDnsZone cmdlet. This creates a DNS zone called corp9172795.com
in the resource group called MyResourceGroup.
References: https://docs.microsoft.com/en-us/azure/dns/dns-getstarted-powershell
QUESTION 13
HOTSPOT
You have an Azure Active Directory (Azure AD) tenant named adatum.com. Adatum.com contains the groups in
the following table:
You create two user accounts that are configured as shown in the following table.
To which groups do User1 and User2 belong? To answer, select the appropriate options in the answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: Group 1 only First rule applies
Box 2: Group1 and Group2 only Both membership rules apply.
References: https://docs.microsoft.com/en-us/sccm/core/clients/manage/collections/create-collections
Testlet 2
Case study
This is a case study. Case studies are not timed separately. You can use as much exam time as you would
like to complete each case. However, there may be additional case studies and sections on this exam. You
must manage your time to ensure that you are able to complete all questions included on this exam in the
time provided.
To answer the questions included in a case study, you will need to reference information that is provided
in the case study. Case studies might contain exhibits and other resources that provide more information
about the scenario that is described in the case study. Each question is independent of the other questions
in this case study.
At the end of this case study, a review screen will appear. This screen allows you to review your answers
and to make changes before you move to the next section of the exam. After you begin a new section, you
cannot return to this section.
To start the case study
To display the first question in this case study, click the Next button. Use the buttons in the left pane
to explore the content of the case study before you answer the questions. Clicking these buttons displays
information such as business requirements, existing environment, and problem statements. If the case study has
an All Information tab, note that the information displayed is identical to the information displayed on the
subsequent tabs. When you are ready to answer a question, click the Question button to return to the question.
Overview
Contoso, Ltd. is a manufacturing company that has offices worldwide. Contoso works with partner organizations
to bring products to market.
Contoso products are manufactured by using blueprint files that the company authors and maintains.
Existing Environment
Currently, Contoso uses multiple types of servers for business operations, including the following:
File servers
Domain controllers
Microsoft SQL Server servers
Your network contains an Active Directory forest named contoso.com. All servers and client computers are
joined to Active Directory.
You have a public-facing application named App1. App1 is comprised of the following three tiers: A SQL database
A web front end
A processing middle tier
Each tier is comprised of five virtual machines. Users access the web front end by using HTTPS only.
Requirements Planned Changes
Contoso plans to implement the following changes to the infrastructure:
Move all the tiers of App1 to Azure.
Move the existing product blueprint files to Azure Blob storage.
Create a hybrid directory to support an upcoming Microsoft Office 365 migration project.
Technical Requirements
Contoso must meet the following technical requirements:
Move all the virtual machines for App1 to Azure.
Minimize the number of open ports between the App1 tiers.
Ensure that all the virtual machines for App1 are protected by backups. Copy the blueprint files to Azure
over the Internet.
Ensure that the blueprint files are stored in the archive storage tier. Ensure that partner access to the
blueprint files is secured and temporary.
Prevent user passwords or hashes of passwprds from being stored in Azure. Use unmanaged standard storage
for the hard disks of the virtual machines.
Ensure that when users join devices to Azure Active Directory (Azure AD), the users use a mobile phone to
verify their identity
Minimize administrative effort whenever possible
User Requirements
Contoso identifies the following requirements for users:
Ensure that only users who are part of a group named Pilot can join devices to Azure AD. Designate a new
user named Admin1 as the service admin for the Azure subscription.
Admin1 must receive email alerts regarding service outages.
Ensure that a new user named User3 can create network objects for the Azure subscription.
QUESTION 1
HOTSPOT
You need to configure the Device settings to meet the technical requirements and the user requirements. Which
two settings should you modify? To answer, select the appropriate settings in the answer area.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Explanation:
Box 1: Selected
Only selected users should be able to join devices
Box 2: Yes
Require Multi-Factor Auth to join devices.
From scenario:
Ensure that only users who are part of a group named Pilot can join devices to Azure AD
Ensure that when users join devices to Azure Active Directory (Azure AD), the users use a mobile phone to
verify their identity.
QUESTION 2
You need to recommend a solution to automate the configuration for the finance department users. The
solution must meet the technical requirements.
What should you include in the recommendation?
A. Azure AD B2C
B. Azure AD Identity Protection
C. an Azure logic app and the Microsoft Identity Management (MIM) client
D. dynamic groups and conditional access policies
Correct Answer: D Section: [none] Explanation
Explanation/Reference:
Explanation:
Scenario: Ensure Azure Multi-Factor Authentication (MFA) for the users in the finance department only.
The recommendation is to use conditional access policies that can then be targeted to groups of users,
specific applications, or other conditions.
References: https://docs.microsoft.com/en-us/azure/active-directory/authentication/howto-mfa-userstates
QUESTION 3
HOTSPOT
You need to implement Role1.
Which command should you run before you create Role1? To answer, select the appropriate options in the
answer area.
NOTE: Each correct selection is worth one point.
Hot Area:
Correct Answer:
Section: [none] Explanation
Explanation/Reference:
Testlet 3 Case study
This is a case study. Case studies are not timed separately. You can use as much exam time as you would
like to complete each case. However, there may be additional case studies and sections on this exam. You
must manage your time to ensure that you are able to complete all questions included on this exam in the
time provided.
To answer the questions included in a case study, you will need to reference information that is provided
in the case study. Case studies might contain exhibits and other resources that provide more information
about the scenario that is described in the case study. Each question is independent of the other questions
in this case study.
At the end of this case study, a review screen will appear. This screen allows you to review your answers
and to make changes before you move to the next section of the exam. After you begin a new section, you
cannot return to this section.
To start the case study
To display the first question in this case study, click the Next button. Use the buttons in the left pane
to explore the content of the case study before you answer the questions. Clicking these buttons displays
information such as business requirements, existing environment, and problem statements. If the case study has
an All Information tab, note that the information displayed is identical to the information displayed on the
subsequent tabs. When you are ready to answer a question, click the Question button to return to the question.
Overview
Humongous Insurance is an insurance company that has three offices in Miami, Tokyo and Bangkok. Each office
has 5.000 users.
Existing Environment
Active Directory Environment
Humongous Insurance has a single-domain Active Directory forest named humongousinsurance.com. The functional
level of the forest is Windows Server 2012.
You recently provisioned an Azure Active Directory (Azure AD) tenant.
Network Infrastructure
Each office has a local data center that contains all the servers for that office. Each office has a
dedicated connection to the Internet.
Each office has several link load balancers that provide access to the servers.
Active Directory Issue
Several users in humongousinsurance.com have UPNs that contain special characters. You suspect that some
of the characters are unsupported in Azure AD.
Licensing Issue
You attempt to assign a license in Azure to several users and receive the following error message:
"Licenses not assigned. License assignment failed for one user."
You verify that the Azure subscription has the available licenses.
Requirements Planned Changes
Humongous Insurance plans to open a new office in Paris. The Paris office will contain 1,000 users who will
be hired during the next 12 months. All the resources used by the Paris office users will be hosted in Azure.
Planned Azure AD Infrastructure
The on-premises Active Directory domain will be synchronized to Azure AD. All client computers in the
Paris office will be joined to an Azure AD domain. Planned Azure Networking Infrastructure
You plan to create the following networking resources in a resource group named All_Resources:
Default Azure system routes that will be the only routes used to route traffic
A virtual network named Paris-VNet that will contain two subnets named Subnet1 and Subnet2 A virtual
network named ClientResources-VNet that will contain one subnet named ClientSubnet
A virtual network named AllOffices-VNet that will contain two subnets named Subnet3 and Subnet4
You plan to enable peering between Paris-VNet and AllOffices-VNet. You will enable the Use remote gateways
setting for the Paris-VNet peerings.
You plan to create a private DNS zone named humongousinsurance.local and set the registration network to
the ClientResources-VNet virtual network.
Planned Azure Computer Infrastructure
Each subnet will contain several virtual machines that will run either Windows Server 2012 R2, Windows
Server 2016, or Red Hat Linux.
Department Requirements
Humongous Insurance identifies the following requirements for the company's departments:
Web administrators will deploy Azure web apps for the marketing department. Each web app will be added to a
separate resource group. The initial configuration of the web apps will be identical. The web administrators
have permission to deploy web apps to resource groups.
During the testing phase, auditors in the finance department must be able to review all Azure costs from
the past week.
Authentication Requirements
Users in the Miami office must use Azure Active Directory Seamless Single Sign-on (Azure AD Seamless SSO)
when accessing resources in Azure.
QUESTION 1
You need to prepare the environment to meet the authentication requirements.
Which two actions should you perform? Each correct answer presents part of the solution.
NOTE: Each correct selection is worth one point.
A. Install the Active Directory Federation Services (AD FS) role on a domain controller in the Miami office.
B. Allow inbound TCP port 8080 to the domain controllers in the Miami office.
C. Join the client computers in the Miami office to Azure AD.
D. Add http://autologon.microsoftazuread-sso.com to the intranet zone of each client computer in the
Miami office.
E. Install Azure AD Connect on a server in the Miami office and enable Pass-through Authentication.
Correct Answer: DE Section: [none] Explanation
Explanation/Reference:
Explanation:
D: You can gradually roll out Seamless SSO to your users. You start by adding the following Azure AD
URL to all or selected users' Intranet zone settings by using Group Policy in Active Directory: https://
autologon.microsoftazuread-sso.com
E: Seamless SSO works with any method of cloud authentication - Password Hash Synchronization or Pass-through
Authentication, and can be enabled via Azure AD Connect.
Incorrect Answers:
A: Seamless SSO is not applicable to Active Directory Federation Services (ADFS). B: Azure AD connect does
not port 8080. It uses port 443.
C: Seamless SSO needs the user's device to be domain-joined, but doesn't need for the device to be Azure
AD Joined.
Scenario: Users in the Miami office must use Azure Active Directory Seamless Single Sign-on (Azure AD
Seamless SSO) when accessing resources in Azure.
Planned Azure AD Infrastructure include: The on-premises Active Directory domain will be synchronized to
Azure AD.
References:
- https://docs.microsoft.com/en-us/azure/active-directory/connect/active-directory-aadconnect-sso-quick-start
You may also refer to other interview preparation articles:
- Linux Interview Questions for Freshers
- Linux Interview Questions for Freshers - 2
- Linux Interview Questions for Freshers and Experienced - L1
- Linux Interview Questions for Experienced Linux Admins - L2
- Advanced Linux Interview Questions for Experienced Admins - L3
- Shell-Scripting interview questions
- OS Network Interview Questions
- GCP ACE Practice Questions - 1st
- GCP ACE Practice Questions - 2nd
- AWS Certified SysOps Administrator - Questions and Answers-1st
- AWS Certified SysOps Administrator - Questions and Answers-2nd
- AWS interview questions for experienced professionals - 1st
- AWS interview questions for experienced professionals - 2nd
- Ansible interview questions
- Kubernetes interview questions
- DevOps Interview Questions for Freshers and Experienced
- DevOps Interview Questions for Freshers and Experienced - 2
- GIT Interview Questions for DevOps Roles
- Jenkins Interview Questions for Experienced DevOps Engineer
- Terraform Interview Questions for Experienced DevOps Engineer
- Terraform Interview Questions for Experienced DevOps Engineer - 2
- Terraform Interview Questions for Experienced DevOps Engineer - 3
- JAVA Interview Questions
- JAVA Interview Questions - 2
- Manual Testing Interview Questions for QA Engineers/Testers
- DBMS Interview Questions
- Managerial interview questions
- Microsoft Azure Administrator AZ-103
You may also explore other articles in our bucket, Happy reading !!:
- What is gcpdiag ?
- What is Artificial Intelligence ?
- What is Machine Learning ?
- Unleashing the Power of Artificial Intelligence
- What is Neural Networks ?
- What is Internet of Things (IoT) ?
- What is Natural Language Processing (NLP) ?
- What is Robotics and Automation ?
- Quantum Computing: The Next Frontier
- Blockchain: A Primer for Beginners
- What is Virtual Reality (VR) ?
- Cybersecurity: Protecting our digital world
- What is AI Chat Open Assistant Chatbot ?
- What is Bard chatbot ?
